Allen Bradley 2711-T5A8L1 HMI Touch Screen SER B, REV E, FRN 4.46 PanelView 550 HMI

I'm Online Chat Now
Great communication., A+ pleasure to do business with, Highly recommend.

—— Michael

Great Suppliers it’s a pleasure to work with you

—— David

quick shipping works great thanks

—— Elaine

Allen Bradley 2711-T5A8L1 HMI Touch Screen SER B, REV E, FRN 4.46 PanelView 550 HMI

Allen Bradley 2711-T5A8L1 HMI Touch Screen SER B, REV E, FRN 4.46 PanelView 550 HMI
Allen Bradley 2711-T5A8L1 HMI Touch Screen SER B, REV E, FRN 4.46 PanelView 550 HMI Allen Bradley 2711-T5A8L1 HMI Touch Screen SER B, REV E, FRN 4.46 PanelView 550 HMI Allen Bradley 2711-T5A8L1 HMI Touch Screen SER B, REV E, FRN 4.46 PanelView 550 HMI

Large Image :  Allen Bradley 2711-T5A8L1 HMI Touch Screen SER B, REV E, FRN 4.46 PanelView 550 HMI Get Best Price

Product Details:

Place of Origin: USA
Brand Name: AB
Certification: CE
Model Number: 2711-T5A8L1

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: 1-500USD
Packaging Details: orginal box
Delivery Time: 2-3 days
Payment Terms: T/T, Western Union
Supply Ability: 30 PCS/ PER Month
Detailed Product Description
Brand: AB Model: 2711-T5A8L1
Type: Touch Screen Origin Of Country: USA
Input Power: 24V DC Display Size: 5.5 In.
High Light:

allen bradley display panel

,

hmi display touch screen

Allen Bradley 2711-T5A8L1 HMI Touch Screen SER B, REV E, FRN 4.46 PanelView 550 HMI



Quick Detials



  • ALLEN BRADLEY

  • 2711-T5A8L1

  • 2711T5A8L1

  • OPERATOR INTERFACE

  • PANELVIEW 550

  • MONOCHROME TOUCHSCREEN TERMINAL

  • 5.5-INCH

  • DH+ COMMUNICATION & RS-232 PRINTER PORT

  • 24 VDC

  • 18 WATT

  • one year warranty



Description:



The 2711-T5A8L1 is part of the Panelview 550 series. It has a 5.5 inch Monochrome display, Touchscreen user input, 24 VDC input power, and has DH+ Communication and RS-232 Printer Port.



About 2711-T5A8L1



The 2711-T5A8L1 PanelView 550 Touchscreen is an electronic operator interface which provides functionality with pixel graphics and a color or monochrome display. It is one of the PanelView Standard 550 terminals that communicate with PLC and SLC controllers over DeviceNet, ControlNet, EtherNet/IP, DH-485, DH+, and remote I/O networks. The 2711-T5A8L1 Panelview 550 has a touch-screen input system, and an LCD monochrome blue display, with an LED backlight. It has a display dimension of 120 x 60 millimeters (4.75 x 2.38 inches), and a display resolution of 128 x 64, with a 100,000-hour, LED back-light standby life. The 2711-T5A8L1 comes with a replaceable battery, and runtime application memory of 170 KB, which runs on a PanelBuilder32 software. It has DataHighWayPlus Communications and an RS-232 communication port, and it supports an ATA Memory card. The input voltage of the 2711-T5A8L1 is between 18 to 32 Volts DC (24 Volts DC nominal), with a maximum power consumption of 18 Watts (0.75 Amps at 24 Volts DC). With a weight of 0.93/1.48 kilograms/pounds, the 2711-T5A8L1 has a dimension of (152 x 185 x 82 millimeters (6.0 x 7.28 x 3.20 inches) The 2711-T5A8L1 has an operating temperaturebetween 0 and 55 degrees Celsius (32 and 131 degrees Fahrenheit), a storage temperature between -20 and 85 degrees Celsius (-4 and 185 degrees Fahrenheit), and a working relative humidity range between 5 and 95% non-condensing at 0 to 55 degrees Celsius (32 to 131 degrees Fahrenheit) working temperature. It has a Shock rating of 30g, and operational vibration of up to 2g.



Technical specifications:

Manufacturer Rockwell Automation
Brand Allen-Bradley
Part Number/Catalog No. 2711-T5A8L1
Product Line Panelview 550
Display Size 5.5 in.
Display Color Monochrome LCD blue mode
Input Type Touchscreen
Communication DH+ Communication and RS-232 Printer Port
Input Power 24V DC
Software Panelbuilder 32
Memory 170 KB application runtime
Backlight 2711-NL1
Communication Cable 2711-NC13
Shipping Weight 5 lbs
Shipping Dimensions 14x11x8 inches
Series A,B,C,D,E,F,G,H
Firmware 1.00-4.48
