ALLEN BRADLEY 2711P-T6C8A 2711P-T6C8D SERIES D PANELVIEW PLUS 600 COLOR TOUCH TERMINAL

ALLEN BRADLEY 2711P-T6C8A 2711P-T6C8D SERIES D PANELVIEW PLUS 600 COLOR TOUCH TERMINAL
ALLEN BRADLEY 2711P-T6C8A 2711P-T6C8D SERIES D PANELVIEW PLUS 600 COLOR TOUCH TERMINAL ALLEN BRADLEY 2711P-T6C8A 2711P-T6C8D SERIES D PANELVIEW PLUS 600 COLOR TOUCH TERMINAL ALLEN BRADLEY 2711P-T6C8A 2711P-T6C8D SERIES D PANELVIEW PLUS 600 COLOR TOUCH TERMINAL

Large Image :  ALLEN BRADLEY 2711P-T6C8A 2711P-T6C8D SERIES D PANELVIEW PLUS 600 COLOR TOUCH TERMINAL Get Best Price

Product Details:

Place of Origin: USA
Brand Name: AB
Certification: CE
Model Number: 2711P-T6C8D

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: 1-500USD
Packaging Details: orginal box
Delivery Time: 2-3 days
Payment Terms: T/T, Western Union
Supply Ability: 30 PCS/ PER Month
Detailed Product Description
Brand: AB Model: 2711P-T6C8D
Type: Touch Screen Origin Of Country: USA
Series: PanelView Plus 600 Power Supply: 24 Volts DC
High Light:

touch screen hmi panels

,

allen bradley display panel

ALLEN BRADLEY 2711P-T6C8A 2711P-T6C8D SERIES D PANELVIEW PLUS 600 COLOR TOUCH TERMINAL



Quick Detials



  • ALLEN BRADLEY
  • 2711P-T6C8D
  • 2711PT6C8D
  • PVP 6IN COLOR DISP
  • TOUCH
  • RS232/ENET/DHAND COM
  • DC
  • one year warranty


Description:

PanelView Plus 600 Operator Interface Terminal with Touchscreen input, 5.7-inch Color Display, and 24 Volts DC Power Supply.



Technical specifications:

Manufacturer Rockwell Automation
Brand
Part Number/Catalog No. 2711P-T6C8D
Series PanelView Plus 600
Module Type Operator Interface Terminal
Input Type Touchscreen
Power Supply 24 Volts DC
Communication RS-232, USB, Ethernet, DH+
Display 5.7-inch Color



About 2711P-T6C8D

The 2711P-T6C8D terminal is an industrial operator interface terminal. It is part of the PanelView Plus 6 series of industrial terminals. The 2711P-T6C8D terminal runs on the Windows CE 4.1 operating system and it comes preloaded with the FactoryTalk View Machine Edition software (version 6.1 or later). The memory on the terminal includes 256 MB RAM and 512 MB of storage, out of which approximately 73 MB is free user memory space. The 2711P-T6C8D terminal is a Series 600 color terminal. Its display size is 5.7 inches and the display is a touchscreen that is based on analog resistive technology. The terminal works on DC input in the 18 to 32 Volts DC voltage range. The typical power consumption of the terminal is 9 Watts and the maximum power consumption is 15 Watts. A protective extra-low voltage (PELV) power supply, a safety extra-low voltage power supply (SELV), or a Class 2 power supply should be used with the terminal. The terminal draws 0.6 Amps of current at 24 Volts DC and 0.375 Amps of current at 24 Volts DC.

The dimensions of the 2711P-T6C8D terminal are 6 x 7.2 x 2.6 inches. A cut-out measuring 4.86 x 6.1 inches is required for the mounting of the terminal. The approximate terminal weight is 1.31 pounds. The communication interfaces on this terminal include Ethernet, RS-234, and DH++ interfaces. The environmental specifications for the 2711P-T6C8D terminal include an operating temperature between 0 and 55 degrees Celsius, a storage temperature between -25 and 70 degrees Celsius, 85 BTU per hour of heat dissipation, a maximum operating altitude of 2000 meters, and an operating shock rating of 15 G at 11 milliseconds. The terminal enclosure type is the NEMA or UL type 12, 14, 4X enclosure and the terminal is designed for indoor use only.
