ORIGINAL Incremental Rotary Encoder Tamagawa TS5212N530 OIH 48-2000P8-L6-5V

Tamagawa TS5212N530 OIH 48-2000P8-L6-5V ORIGINAL Rotary Encoder

Specifications

Incremental Encoders

Incremental encoders generate pulses in a frequency proportional to the rotational speed. The encoders can be used for speed control, position control, or as a rotation indicator or a pulse generator of servo motors mounted in machine tools,robots,or measuring equipment.Optical incremental encoders are composed of rotor plate, fixed slit, light emitting diodes, photo transistors, etc. as shown in Figure 1.The fixed slit is designed to have 90 degree phase difference to the slit on the rotor plate.Output signals are two signals with 90 degrees difference; A-phase signal and B-phase signal, and the rotational direction can be detected with them.There are encoders which output the additional Z-phase signal as the origin signal.When controlling positions with an incremental encoder, the Z signal which shows the origin is used.

Incremental Encoder Simplified Structure

Magnetic Encoder Simplified Structure

Similiar Servo Motor Encoder:

Mitsubishi servo encoder
When extreme high speed and accuracy is essential for your application, Mitsubishi's linear servos are the perfect solution. With 17 core type (liquid cooled) models ranging from 60N to 18000N and 9 coreless types in the range of 50N to 3200N, our linear servo technology offers high power density in a compact package, improved heat dissipation, and extremely smooth motion. Designed for easy-of-use, our motors seamlessly integrate with our MR-J3-RJ004 type amplifiers allowing for seamless start up and faster project development as well as a "Robust Disturbance compensation function" that suppresses offset disturbances that cause uneven speeds. Mitsubishi's linear motors have a successful history in many industries ranging from semiconductor manufacturing to machine tools. Set-up, diagnostics, and tuning are easy for all Mitsubishi's servos, thanks to MR-Configurator, our Windows based software package.
