1500 Terminal HMI Touch Screen Allen Bradley PanelView Plus 2711P-B15C4A9

1500 Terminal HMI Touch Screen Allen Bradley PanelView Plus  2711P-B15C4A9
1500 Terminal HMI Touch Screen Allen Bradley PanelView Plus  2711P-B15C4A9 1500 Terminal HMI Touch Screen Allen Bradley PanelView Plus  2711P-B15C4A9 1500 Terminal HMI Touch Screen Allen Bradley PanelView Plus  2711P-B15C4A9

Large Image :  1500 Terminal HMI Touch Screen Allen Bradley PanelView Plus 2711P-B15C4A9 Get Best Price

Product Details:

Place of Origin: USA
Brand Name: AB
Certification: CE
Model Number: 2711P-B15C4A9

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: 1-500USD
Packaging Details: orginal box
Delivery Time: 2-3 days
Payment Terms: T/T, Western Union
Supply Ability: 30 PCS/ PER Month
Detailed Product Description
Brand: AB Model: 2711P-B15C4A9
Type: Touch Screen Origin Of Country: USA
Product Line: Panelview 6 Plus Input Power: 100-240 VAC
High Light:

touch screen hmi panels

,

hmi display touch screen

Allen Bradley PanelView Plus 1500 2711P-B15C4A9 HMI Touch Screen

Quick Detials



  • ALLEN BRADLEY

  • 2711P-B15C4A9

  • 2711PB15C4A9

  • OPERATOR INTERFACE 15INCH TOUCHSCREEN COLOR

  • one year warranty


Description:



PanelView Plus 6 Operator interface , 1500 Terminal, with Keypad/Touch, Color display, - Ethernet & RS-232, AC Powered Unit, and the Windows CE 6.0 Operating System with Extended Features





About 2711P-B15C4A9



The current Allen Bradley Panelview 6 Plus 2711P-B15C4A9 is an HMI that allows the user to interact with their machine. This operator interface has a 15 in. Color Display. This Panelview Plus 6 allows the user to connect using FactoryTalk View Machine Edition software and an Ethernet and RS-232 communication port with a 2711-NC14 communication cable(s). The user is able to control the operator interface by utilizing the Keypad/Touchscreen to input information and data. This unit is powered using 100-240 VAC power. This unit has the following internal memory: 512 MB RAM. If applicable this unit has an internal backlight replacement part number of 2711P-RL15C. The approximate shipping weight and dimensions are 13 lbs. and 20 x 14 x 8 in. The most common Series are Series A and Series B and the most common firmware include 6.00-8.10. EtherNet/IP (Ethernet Industrial Protocol) is an open industrial network that supports real time I/O messaging, as well as message exchange. The Ethernet port connects to a controller on an EtherNet/IP network by using both the network and standard Ethernet connections. This port can work with application transfers and printing as well. The EtherNet/IP screen displays and allows the user to modify some of the EtherNet/IP communication settings for a PanelView terminal. The 2711P-RN20 Ethernet communication module is available for the 700 to 1500 terminals if another Ethernet port is required. The module has its own unique IP address. This port has an RJ45, 10/100Base-T connector for network communication and supports MDI/MDI-X connections. The parameters are downloaded with the application.



Technical specifications:

Manufacturer

Rockwell Automation

Brand

Part Number/Catalog No.

2711P-B15C4A9

Product Line

Panelview 6 Plus

Display Size

15 in.

Display Color

Color

Input Type

Keypad/Touchscreen

Communication

Ethernet and RS-232

Input Power

100-240 VAC



Software

FactoryTalk View Machine Edition

Memory

512 MB RAM

Backlight

2711P-RL15C

Communication Cable

2711-NC14

Shipping Weight

13 lbs.

Shipping Dimensions

20 x 14 x 8 in

Series

Series A and Series B

Firmware

6.00-8.10
