2711P-T10C4A8 2711P-T10C4A9 Touch Screen AB PANELVIEW PLUS 10.4"ASSEMBLED TERMINAL MODULE.NEW IN BOX

I'm Online Chat Now
Great communication., A+ pleasure to do business with, Highly recommend.

—— Michael

Great Suppliers it’s a pleasure to work with you

—— David

quick shipping works great thanks

—— Elaine

2711P-T10C4A8 2711P-T10C4A9 Touch Screen AB PANELVIEW PLUS 10.4"ASSEMBLED TERMINAL MODULE.NEW IN BOX

2711P-T10C4A8 2711P-T10C4A9 Touch Screen AB PANELVIEW PLUS 10.4"ASSEMBLED TERMINAL MODULE.NEW IN BOX
2711P-T10C4A8 2711P-T10C4A9 Touch Screen AB PANELVIEW PLUS 10.4"ASSEMBLED TERMINAL MODULE.NEW IN BOX 2711P-T10C4A8 2711P-T10C4A9 Touch Screen AB PANELVIEW PLUS 10.4"ASSEMBLED TERMINAL MODULE.NEW IN BOX 2711P-T10C4A8 2711P-T10C4A9 Touch Screen AB PANELVIEW PLUS 10.4"ASSEMBLED TERMINAL MODULE.NEW IN BOX

Large Image :  2711P-T10C4A8 2711P-T10C4A9 Touch Screen AB PANELVIEW PLUS 10.4"ASSEMBLED TERMINAL MODULE.NEW IN BOX Get Best Price

Product Details:

Place of Origin: USA
Brand Name: AB
Certification: CE
Model Number: 2711P-T10C4A8

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: 1-500USD
Packaging Details: orginal box
Delivery Time: 2-3 days
Payment Terms: T/T, Western Union
Supply Ability: 30 PCS/ PER Month
Detailed Product Description
Brand: AB Model: 2711P-T10C4A8
Type: Touch Screen Origin Of Country: USA
Series: A And B Firmware: 6.00 To 8.10
High Light:

touch screen hmi panels

,

allen bradley display panel

2711P-T10C4A8 2711P-T10C4A9 Touch Screen AB PANELVIEW PLUS 10.4"ASSEMBLED TERMINAL MODULE.NEW IN BOX



Quick Detials



  • ALLEN BRADLEY
  • 2711P-T10C4A8
  • 2711PT10C4A8
  • OPERATOR INTERFACE
  • TOUCH SCREEN
  • PANELVIEW PLUS 6
  • 1000 COLOR TERMINAL 10.4 INCH
  • STANDARD COMMUNICATION: ETHERNET AND RS-232
  • 512 MB FLASH
  • 512 MB RAM
  • 100-240 VAC INPUT
  • 50/60 HZ
  • one year warranty


Description:

PanelView Plus 6 Operator interface , 1000 Terminal, with Touchscreen, Color display, - Ethernet & RS-232, AC Powered Unit, and the Windows CE 6.0 Operating System



Technical specifications:

Manufacturer Rockwell Automation
Brand
Part Number/Catalog No. 2711P-T10C4A8
Product Line Panelview 6 Plus
Product Type HMI
Display Size 10.4 inches
Display Color Color
Input Type Touchscreen
Communication Ethernet and RS-232
Input Power 100 to 240 Volts AC
Software FactoryTalk View Machine Edition
Memory 512 MB RAM
Backlight 2711P-RL10C2
Communication Cable 2711-NC13
Shipping Weight 8 pounds
Shipping Dimensions 16 x 14 x 8 inches
Series A and B
Firmware 6.00 to 8.10



About 2711P-T10C4A8

The 2711P-T10C4A8 PanelView Plus 6 Terminal is a Human-Module Interface (HMI) with an interactive graphics display that makes controlling a machine easy. The 2711P-T10C4A8 provides users with flexible configuration through the separate logic module and display module, and the communication modules. It arrives preloaded and activated with FactoryTalk View Machine Edition software and FactoryTalk ViewPoint software. Various HMI applications can also be developed with the FactoryTalk View Studio software.
The 2711P-T10C4A8 Terminal has a 10.4-inch TFT display with resistive touchscreen input. The native resolution is 640 x 480 pixels with 18-bit color graphics. It has 512 MB of RAM and 512 MB of nonvolatile memory for data storage. The 2711P-T10C4A8 weighs 8 pounds and measures 16 x 14 x 8 inches. It requires an input voltage of 100 to 240 Volts AC at 50 to 60 Hertz with a 160 VA maximum power consumption. For communication, it has Ethernet and RS-232 serial ports with optional DH-485, DH+, and ControlNet module ports. The 2711P-T10C4A8 also has 2 USB ports for connecting external devices such as keyboards and flash drives. This 2711P-T10C4A8 PanelView Plus 6 allows the user to connect using FactoryTalk View Machine Edition software and an Ethernet and RS-232 communication port with a 2711-NC13 communication cable(s). The user is able to control the 2711P-T10C4A8 operator interface by utilizing the touchscreen to input information and data.

The 2711P-T10C4A8 runs on the Windows CE 6.0 operating system providing common user functionalities such as a VNC client server, an FTP server, ActiveX controls, a built-in pdf viewer, and third-party device support. For data backup and logging, it also supports an SD card. The 2711P-T10C4A8 includes a real-time clock for timestamping critical data. The clock is battery-backed, and it has a minimum battery life of 4 years. It has major improvements over its predecessors in the areas of speed, transition rate, system memory, storage space, and backlight illumination. The most common Series are Series A and Series B and the most common firmware include 6.00 to 8.10.



MORE INFORMATION

DELIVERY

Logistic partners UPS, FedEx and DHL

International delivery available

Same day dispatch from group stock


WARRANTY

All parts new are covered by Shenzhen Viyork 12 month warranty


RETURNS

No hassle returns policy

Dedicated customer support team


PAYMENT

Trade credit


We understand that credit is a necessary part of business and offer credit agreements on request, subject to status.


Payment options

We accept Bank transfers and the following methods of payment:

Western Union PayPal VISA
