Allen Bradley 2711P-T12C4D9 PanelView Plus 6 1250 Touchscreen 512MB #1

Allen Bradley 2711P-T12C4D9 PanelView Plus 6 1250 Touchscreen 512MB #1
Allen Bradley 2711P-T12C4D9 PanelView Plus 6 1250 Touchscreen 512MB #1 Allen Bradley 2711P-T12C4D9 PanelView Plus 6 1250 Touchscreen 512MB #1 Allen Bradley 2711P-T12C4D9 PanelView Plus 6 1250 Touchscreen 512MB #1

Large Image :  Allen Bradley 2711P-T12C4D9 PanelView Plus 6 1250 Touchscreen 512MB #1 Get Best Price

Product Details:

Place of Origin: USA
Brand Name: AB
Certification: CE
Model Number: 2711P-T12C4D9

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: 1-500USD
Packaging Details: orginal box
Delivery Time: 2-3 days
Payment Terms: T/T, Western Union
Supply Ability: 30 PCS/ PER Month
Detailed Product Description
Brand: AB Model: 2711P-T12C4D9
Type: Touch Screen Origin Of Country: USA
Shipping Weight: 10 Pounds Firmware: 6.00-8.10
High Light:

touch screen hmi panels

,

allen bradley display panel

Allen Bradley 2711P-T12C4D9 PanelView Plus 6 1250 Touchscreen 512MB #1



Quick Detials



  • ALLEN BRADLEY
  • 2711P-T12C4D9
  • 2711PT12C4D9
  • 09 /2019
  • PANELVIEW PLUS 6 1250 TERMINAL
  • 12.1-INCH
  • COLOR
  • TOUCH SCREEN
  • STANDARD COMMUNICATIONS (ETHERNET & RS-232)
  • 512 MB FLASH
  • 512 MB RAM
  • WINDOWS CE 6.0 WITH EXTENDED FEATURES AND FILE VIEWERS
  • 24 VDC POWER
  • one year warranty


Description:

PanelView Plus 6 Operator interface , 1250 Terminal, with Touchscreen, Color display, - Ethernet & RS-232, DC Powered Unit, and the Windows CE 6.0 Operating System with Extended Features



Technical specifications:

Manufacturer Rockwell Automation
Brand
Part Number/Catalog No. 2711P-T12C4D9
Product Line Panelview 6 Plus
Display Size 12.1 inches
Display Color Color
Input Type Touchscreen
Communication Ethernet and RS-232
Input Power 18 to 32 Volts DC
Software FactoryTalk View Machine Edition
Memory 512 MB RAM
Backlight 2711P-RL12C2
Communication Cable 2711-NC13
Shipping Weight 10 pounds
Shipping Dimensions 20 x 14 x 8 inches
Series Series A and Series B
Firmware 6.00-8.10



About 2711P-T12C4D9

The 2711P-T12C4D9 terminal is an operator interface under the 1250 series of PanelView Plus 6 terminal series. The 2711P-T12C4D9 terminal is a flat-panel touchscreen interface terminal that comes with extended features that let the users control, monitor, and visualize information on application status graphically. The resistive 8-wire analog touchscreen of the terminal offers a 1-million press actuation rating with 10 to 110 G of operating force. This highly recommended graphic terminal features a 12.1-inch enhanced color display with an active-matrix TFT LCD and a backlight with 50,000 hours of life. The terminal has 800 x 600 pixels of maximum resolution with 18-bit color graphics and it has 300 cd/m2 Nits (2) of luminance. The display area measures 9.7 x 7.2 inches. The estimated shipping weight of the 2711P-T12C4D9 terminal is 7.0 pounds, while the panel cut-out dimensions are 10.11 inches in height and 13.29 inches in width. Moreover, the 2711P-T12C4D9 terminal provides 12 MB of non-volatile flash memory and 512 MB of RAM. The terminal is available with communication ports such as Ethernet and RS-232 ports. Users can transfer data and applications to a personal computer via the USB communication port and the RS-232 port of the terminal. The terminal supports the FactoryTalk View ME Station 6.0 software and it runs on the Windows CE 6.0 operating system.

The input DC voltage range of the 2711P-T12C4D9 terminal is 18 to 32 Volts DC and 24 Volts DC nominal. On the other hand, the terminal supplies an input AC voltage of 85 to 264 Volts AC at 47 to 63 Hertz. The power consumption capacity is 70 W maximum and 2.9 Amps at 24 Volts DC. The AC power consumption capacity is rated at 160 Volts AC. The external power supply of the DC-powered terminals in the 700 to 1500 series is given at 264 Volts AC at 120 VA maximum. In addition, the 2711P-T12C4D9 terminal has a 32 to 131 degrees Fahrenheit operating temperature range at 5 to 95% relative humidity without condensation. Also, it operates at a vibration of 2 G at 7 to 500 Hertz and it is fabricated for operating optimally at 2000 meters or 6561 feet of maximum altitude without any power loss. Moreover, the operational shock rating is 15 G while the non-operating shock rating is 30 G. The 2711P-T12C4D9 terminal is protected by a NEMA Type 12 /13 enclosure designed. The thermal dissipation in an operating state is 240 BTU/hour.
