Allen Bradley 2711P-T15C4D8 2711P-T15C4D9 HMI Touch Screen PANELVIEW PLUS 15" Assembled Terminal Module

I'm Online Chat Now
Great communication., A+ pleasure to do business with, Highly recommend.

—— Michael

Great Suppliers it’s a pleasure to work with you

—— David

quick shipping works great thanks

—— Elaine

Allen Bradley 2711P-T15C4D8 2711P-T15C4D9 HMI Touch Screen PANELVIEW PLUS 15" Assembled Terminal Module

Allen Bradley 2711P-T15C4D8 2711P-T15C4D9 HMI Touch Screen PANELVIEW PLUS 15" Assembled Terminal Module
Allen Bradley 2711P-T15C4D8 2711P-T15C4D9 HMI Touch Screen PANELVIEW PLUS 15" Assembled Terminal Module Allen Bradley 2711P-T15C4D8 2711P-T15C4D9 HMI Touch Screen PANELVIEW PLUS 15" Assembled Terminal Module Allen Bradley 2711P-T15C4D8 2711P-T15C4D9 HMI Touch Screen PANELVIEW PLUS 15" Assembled Terminal Module Allen Bradley 2711P-T15C4D8 2711P-T15C4D9 HMI Touch Screen PANELVIEW PLUS 15" Assembled Terminal Module

Large Image :  Allen Bradley 2711P-T15C4D8 2711P-T15C4D9 HMI Touch Screen PANELVIEW PLUS 15" Assembled Terminal Module Get Best Price

Product Details:

Place of Origin: USA
Brand Name: AB
Certification: CE
Model Number: 2711P-T15C4D8

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: 1-500USD
Packaging Details: orginal box
Delivery Time: 2-3 days
Payment Terms: T/T, Western Union
Supply Ability: 30 PCS/ PER Month
Detailed Product Description
Brand: AB Model: 2711P-T15C4D8
Type: Touch Screen Origin Of Country: USA
Memory: 512 MB RAM Firmware: 6.00 To 8.10
High Light:

touch screen hmi panels

,

allen bradley display panel

2711P-T15C4D8 2711P-T15C4D9 Touch Screen PANELVIEW PLUS 15" ASSEMBLED TERMINAL MODULE .NEW IN BOX



Quick Detials



  • ALLEN BRADLEY
  • 2711P-T15C4D8
  • 2711PT15C4D8
  • OPERATOR INTERFACE
  • 15INCH
  • 2711 SERIES
  • PANELVIEW PLUS 6
  • HMI TERMINAL
  • 1500 MODEL
  • TOUCH SCREEN
  • COLOR
  • one year warranty


Description:

The 2711P-T15C4D8 is a PanelView Plus 6 Operator interface. This is a 1500 Terminal with a Touchscreen Color display. It has both Ethernet and RS-232 ports and is a DC Powered Unit; this module has a Windows CE 6.0 Operating System.



Technical specifications:

Manufacturer Rockwell Automation
Brand
Part Number/Catalog No. 2711P-T15C4D8
Product Line Panelview 6 Plus
Display Size 15 inches
Display Type Color
Input Type Touchscreen
Communication Ethernet and RS-232 ports
Input Power 18 to 32 Volts DC
Software FactoryTalk View Machine Edition
Memory 512 MB RAM
Backlight 2711P-RL15C
Communication Cable 2711-NC13
Shipping Weight 13 pounds
Shipping Dimensions 20 x 14 x 8 inches
Series Series A and Series B
Firmware 6.00 to 8.10
Enclosure Rating NEMA/UL Type 12,13, 4X and IEC IP54, IP65
Display Module 2711P-RDT15C
Logic Module 2711P-RP8D
Mounting Hardware 2711P-RTMC



About 2711P-T15C4D8

The 2711P-T15C4D8 is an PanelView Plus 6-1500 Model terminal. This PanelView Plus 6-1500 Model terminal is an HMI (Human-Module Interface) that allows the user to interact with their machine by monitoring, managing, and displaying application status information. This operator interface has a 15 in. Color Display Module (2711P-RDT15C). This 2711P-T15C4D8 Panelview Plus 6 allows the user to connect using FactoryTalk View Machine Edition software and an Ethernet and RS-232 communication port with a 2711-NC13 communication cable(s). The user is able to control the operator interface via the Touchscreen to input information and data. This unit is powered using an 18 to 32 Volt DC power input. This 2711P-T15C4D8 unit has a 512 MB of RAM of internal memory. The approximate shipping weight and dimensions of this unit are 13 pounds and 20 x 14 x 8 inches. The most common Series for this module are Series A and Series B, and it usually includes a firmware between 6.00 and 8.10.

This module's Ethernet port connects to a controller on an Ethernet/IP network by using both the network and standard Ethernet connections. This port can work with application transfers and printing as well. The Ethernet/IP screen displays and allows the user to modify some of the Ethernet/IP communication settings for a PanelView terminal. The 2711P-RN20 Ethernet communication module is available for the 700 to 1500 terminals if another Ethernet port is required. The module has its own unique IP address; this port has an RJ45, 10/100Base-T connector for network communication and supports MDI/MDI-X connections. The parameters are downloaded with the application. This unit requires mounting hardware which has a part number of 2711P-RTMC.
