Product Details:
Payment & Shipping Terms:
|
| Brand: | AB | Model: | 1746-IV32 |
|---|---|---|---|
| Type: | I/O Adapter Module | Origin Of Country: | USA |
| Series: | SLC 500 | Voltage Range: | 15-30 Volts DC Source |
| High Light: | allen bradley memory module,plc processor module |
||
Allen Bradley 1746-IV32 Ser. D Source Input Module SLC 500 1746IV32 15 - 30 VDC New
Quick Detials
one year warranty
Specifications:
The 1746-IV32 is a SLC 500 Digital DC Input Module. This Digital DC Input Module has a Voltage Range of 15-30 Volts DC Source and 32 Inputs. It is intended for General Purpose DC Inputs Applications.
The 1746-IV32 SLC 500 32 Channel Digital Input Module by is a 24V DC current sourcing input module with 32 inputs and 8 points per fused common that is fixed in any slot of the SLC 500 chassis. It has an operating voltage range between 15 and 30V DC at 50 °C and a range of 15 and 26.4V DC at 60 °C and it has a backplane draw current of 0.05A at 5V DC. The 1746-IV32 has a non-replaceable electronically-fused common with the fuse rated at 2.5A and it provides a 60s 1500V AC-tested isolation from the backplane.
The signal delay on the input points has a maximum delay time of 3ms for both the ON and OFF states and the module has a maximum OFF-state current of 1.5mA. It also has a minimum ON-state voltage of 15V DC and a maximum OFF-state voltage of 5V DC. It has a nominal input current of 5.1mA per point and the maximum heat dissipation on each point is 0.2W with an aggregate of 6.65W for the whole module. The 1746-IV32 is CE, CSA, and UL-certified and it provides NEMA standard ICS 2-230 Noise immunity. It is designed and tested to withstand a working vibration of 2.5G at 57-200Hz with a tested peak displacement of 0.015 inches and maintains an optimal function even with an operational shock of 30G. It has a working temperature between 0 and 60 °C at a relative humidity range of 5-95%.
Technical specifications:
| Manufacturer | AB |
| Brand | |
| Part Number/Catalog No. | 1746-IV32 |
| Series | SLC 500 |
| Module Type | Digital DC Input Module |
| Voltage Range | 15-30 Volts DC Source |
| Inputs | 32 |
| Backplane Current (5 Volts DC) | 106 milliamps |
| Signal delay | 3 milliseconds |
| Off State Current | 1 milliamp |
| Applications | General Purpose DC Inputs |
| Applications | Combination 120 Volts AC I/O |
