New 2711P-T6C20D8 2711P-T6C20D9 Sealed Panelview Plus 600 FS Ethernet HMI

Large Image : New 2711P-T6C20D8 2711P-T6C20D9 Sealed Panelview Plus 600 FS Ethernet HMI Get Best Price

Product Details:

Place of Origin:	USA
Brand Name:	AB
Certification:	CE
Model Number:	2711P-T6C20D8

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Price:	1-500USD
Packaging Details:	orginal box
Delivery Time:	2-3 days
Payment Terms:	T/T, Western Union
Supply Ability:	30 PCS/ PER Month

Contact Now

Detailed Product Description

Brand:	AB	Model:	2711P-T6C20D8
Type:	Touch Screen	Origin Of Country:	USA
Firmware:	7.00 To 8.10	Memory:	512 MB
Highlight:	touch screen hmi panels , allen bradley display panel

New 2711P-T6C20D8 2711P-T6C20D9 Sealed Panelview Plus 600 FS Ethernet HMI

Quick Detials

ALLEN BRADLEY
2711P-T6C20D8
2711PT6C20D8
OPERATOR INTERFACE
6 INCH
TOUCHSCREEN
COLOR
PANELVIEW
PANELVIEW PLUS 600 TERMINAL
5.7-INCH
TOUCH SCREEN
STANDARD COMMUNICATIONS (ETHERNET & RS-232)
512 MB FLASH
256 MB RAM
WINDOWS CE 6.0
24 VDC
one year warranty

Description:

The 2711P-T6C20D8 is a PanelView Plus 6 Operator interface is a 600 Terminal and comes with a Touchscreen, a Color display, and Ethernet and RS-232 Communication. It is a 24 Volts DC Powered Unit and has a Windows CE 6.0 Operating System. FactoryTalk View Machine Edition Software. Non-replaceable backlight.

Technical specifications:

Manufacturer	Rockwell Automation
Brand
Part Number/Catalog No.	2711P-T6C20D8
Product Line	Panelview 6 Plus
Display Size	5.7 inches
Display Color	Color
Input Type	Touchscreen
Communication	Ethernet and RS-232
Input Power	18 to 30 Volts DC

Software	FactoryTalk View Machine Edition
Memory	256 MB RAM
Backlight	Non-replaceable
Communication Cable	2711-NC13
Shipping Weight	6 pounds
Shipping Dimensions	14 x 11 x 8 inches
Series	Series A and Series B
Firmware	7.00 to 8.10
Flash Storage	512 MB

About 2711P-T6C20D8

The 2711P-T6C20D8 is a PanelView Plus 6 - 600 Terminal that is made by . The 2711P-T6C20D8 is an operator interface that allows the operators to monitor, manage, and display application status information about the machine. This terminal has modular components that allow for flexible configuration, installation, and upgrades. This unit is powered via 24 Volts DC input power. It comes with USB, RS-232, and Ethernet ports for communication with other devices. As a part of the 600 Series of the PanelView Plus 6 terminals, the 2711P-T6C20D8 offers the open-platform flexibility of the Windows CE operating system and it offers compatibility with the FactoryTalk View Studio Machine Edition software. The 2711P-T6C20D8 also comes with developed software and with a feature for the real-time monitoring of terminal displays through a web browser. This is a common feature of all the PanelView Plus 6 HMI panels.

The 2711P-T6C20D8 processor's speed has increased from 350 MHz to 1 GHz and the screen transition rate is approximately 70% faster than the same rate in previous models. The system memory has been increased from 64 MB of RAM to 256 MB of RAM and the flash storage space has increased from 64 MB to 512 MB. The illumination power of the backlight displays has also increased. Additionally, the 2711P-T6C20D8 provides greater connectivity to a variety of external hardware options such as printers, mice, and keyboards. This PanelView Plus 6 2711P-T6C20D8 supports ActiveX Controls and it integrates with third-party software such as Microsoft Internet Explorer. Optional communication modules can be ordered for additional network communication.
