Product Details:
Payment & Shipping Terms:
|
| Brand: | Yaskawa | Model: | SGDB-1AADGY68 |
|---|---|---|---|
| Type: | Industrial Servo Drive | Power: | 900W |
| AC-INPUT: | 3PH 200-230V 50/60HZ 60A | AC-OUTPUT: | 3PH 0-230V 49A |
| High Light: | Yaskawa Industrial Servo Drives,900W Industrial Servo Drives,900W Yaskawa Servo Amplifier |
||
3 Phase SGDB 1AADGY68 900W Yaskawa Industrial Servo Drives 10 AMP
3 Phase SGDB-1AADGY68 10 AMP Industrial Servo Drives AC 230V Input
Quick Details:
YASKAWA ELECTRIC
One Year Warranty
Specifications
| Viyork Stock No72001 | Brand/ManufacturerYaskawa | Manufacturer Part Number SGDB-1AADGY68 |
| Product typeServo Drive | Phase1;3 | Control functionServo Control |
| Supply voltage200 to 230 V ac | Current rating60.0 mA | Width110 mm |
| Depth225 mm | Height250 mm | Minimum operating temperature0 °C |
| Maximum operating temperature55 °C | Power rating9.0kW;1.3 hp |
SGDB Series SERVOPACK
The operation of the SGDB SERVOPACK is basedon commands sent via serial communications or contacts.
Information of motor position is managed within the SERVO-PACK, and there is no need to form a speed or position feedback loop between
the host controller and SERVOPACK.
Furthermore, acceleration and deceleration patterns can also be created based on user settings within the SERVOPACK.
Using the SGDB SERVOPACK
Operation Modes
The SGDB SERVOPACK has four operation modes.
These modes can be switched at any time by means of a contact.
Automatic Mode
Following the input of command position data, the input of an operation start signal performs
the positioning based on the input data.
The operation method in automaticmode canbe selectedfrom thefollowing: Stationnumbers,
digital switches, serial communications, and command table.
Manual Mode
The Servomotor runs at a constant speed while a manual mode signal is being input.
Pulse Mode
Positioning is performed by a pulse train command from an external pulse generator.
1. Pulse system: Line driver, line receiver
2. Pulse form: Two-phase pulse trains with 90° phase difference (×1) (450 kpps max.)
Sign + pulse train (450 kpps max.)
CW + CCW pulse trains (450 kpps max.)
An external PG input is triggered when an /LPG signal is input.
